Features:
- IP67 Waterproof and Dustproof
- High Power, Long Range Handheld Radio
- Rugged Construction, Shockproof and drop-resistant
- Large Capacity Battery
- Voice Compander
- Frequency Hopping
- VOX Hands-free Function
- TOT
- Low Battery Reminder
- FCC&CE Certified
- SQL
CD-A8 heavy duty walkie talkie is designed for many harsh job sites. It features a rugged construction and advanced triple proof performance. It can support reliable communication even in tough environments, such as job sites and construction sites.
IP67 Waterproof
CD-A8 is a professional walkie talkie. It is waterproof. It can withstand 30 minutes at a depth of up to 1 meter after being tested by the laboratory.
Long Range Communications
CD-A8 has a maximum transmission power of 10W, making it a long-range heavy duty two way radio. It offers a call distance of 10 kilometers.
Triple Proof
CD-A8 radio is ideal for use in heavy-duty industry. It is waterproof, dustproof, and drop-resistant.
Clear Sound
CD-A8 adopts DSP noise reduction technology. It can recognize human voices and filter background noise to deliver clear voice message.
Long Battery Life
With 2900mAh rechargeable battery, CD-A8 radio can outlast for 200 hours. It also has low battery reminder to notify you when the radio runs out of power.
Standard Package:
- Radio*1
- Battery*1
- Antenna*1
- Belt Clip*1
- Charger*1
- Strap*1
- Users’ Manual*1
Technical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz UHF:400-480MHz |
Output Power | 10W | RF Sensitivity | ≤ 0.25uV/ ≤ 0.3uV |
| Channel Spacing | 16 | Current | ≤2.5A | Silent Sensitivity | ≤0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz / 25 KHz | Modulation Distortion | <5%(300-3000Hz) | Audio Frequency Power | ≥500mW |
| Rated Voltage | 7.4V DC | Maximum Frequency Deviation |
≤ 5KHz/≤ 2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2900mAh | CTCSS Frequency Deviation |
0.75KHz± 50Hz | Modulation Receiver Bandwidth |
±7KHz |
| Frequency Sensitivity | ± 2.5ppm | Remanent Radiation | ≤7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | 16K∅F3E/11K∅F3E | Selectivity | ≥65dB |
| Dimension | 128×58.5x39mm (Without Antenna) |
Remanent Modulation | ≤-35dB | Intermodulation | ≥60dB |
Resources:
→Download CD-A8 manual
